Asset RFID for Oil Industry

Introduction

BISA Asset RFID (FM certified) is 2.45GHz Active RFID that specially designed for locating and information management of various Oil Assets, such as oil valves, pumps, pipes etc, all are mentallic assets in hazardous area. The maintenance history of assets can be collected and provided in real-time and each oil assets can be located by RFID system which promote the asset informational management.



The structure of the system

Key Functions of Asset RFID System:

(1) Basic information log of assets is including asset name, asset type, asset serial no, asset assignment & asset use status (such as active in-use, return to storage, rental for specific project etc.), asset location and authorization level etc.

(2) Real-time locating the target assets from system, quickly find the assets that need to deal with. Shorten the time of searching target asset and reduce much labor cost.

(3) Electronic Patrol and Inspection of assets in using. Improve the factuality and timeliness management of staff asset patrol

(4) Track the life-cycle use of oil assets, log the asset maintenance history by handheld RFID reader from New Asset imported to expire. The real time log and acquire of asset maintenance history by RFID largely reduces the high labor cost (staff have to log the assets maintenance history into data center by mandate input according to the asset label records) and promote the timeliness of information input without any delay.

Intrinsic-Safe Asset Tag
BISA Explosion-proof Asset Tag is FM certification pending 2.45GHz Active RFID tag with RoHS compliance, predominant hot and cold impact resistance, and drop resistance features. Also the adhesive label chemical compatibility and enclosure surface insulation resistance are very good.

Features:
Intrinsic-safe low power consumption design;
R/W function enables end-user to write relevant information into asset tag;
Predominant anti-collision feature that can read 100 tag message every second and mange over 2000 tag in field.
High Anti-metal nature makes RF signal reliable though affix to mental items.
Special hole-design at two ends of asset tag makes it easily be affixed to asset by tag string.



Intrinsic-Safe Reader (Fixed)
BISA Explosion-proof Fixed Reader is FM certification pending 2.45GHz RFID reader with RoHS compliance, predominant hot and cold impact resistance, and drop resistance features. Also the adhesive label chemical compatibility and enclosure surface insulation resistance are very good.

Features:
Intrinsic low power consumption design;
Long communication range with asset tag, up to 100 meters and adjustable;
Long communication range (5Km without Repeater) of reader network (CAN-bus interface);
Locate target asset in real-time and showed in a real geography map if GIS system integrated;
Predominant anti-collision feature that can read 100 tag message every second and mange over 2000 tag in field.



Intrinsic-Safe Handheld Reader
BISA Explosion-proof Fixed Reader is FM certification pending 2.45GHz RFID reader with RoHS compliance, predominant hot and cold impact resistance, and drop resistance features. Also the adhesive label chemical compatibility and enclosure surface insulation resistance are very good.

Features:
Intrinsic low power consumption design;
Reader integrated with PDA with WinCE platform;
Mini dimension and fulfill movable Read and Write operation on asset tag;
Electronic Patrol function for assets.
